ARBITER

Precision Timing Products Selection Guide

A = Available on all versions (A/B/C) unless otherwise specified
S = Standard on all versions (A/B/C) unless otherwise specified

Specification	1083	1084	1088	1092	1093	1094	1095
Accuracy
100 ns	S	S	S
250 ns						S	S
500 ns				S	S
Inputs
GPS L1 Code (1575.42 MHz)	S	S	S	S	S	S	S
Event Timer(s) / 1PPS Deviation		S	S	S	S	S	S
Outputs
IRIG-B Modulated		S	S	A	A	S	S
IRIG-B Unmodulated		S	S	S	S	S	S
IRIG-B Modified Manchester		S	S	A	A	S	S
IRIG-B IEEE 1344		S	S	S	S	S	S
1 Pulse-Per-Second (PPS)	S	S	S	S	S	S	S
Programmable Pulse		S	S	S	S	S	S
50, 60 PPS			S
10, 100, 1k, 10k,100k PPS		S	S
1M, 5M, 10M PPS		S	S
1M, 5M, 10M Hz (Sinusoid)	S
IRIG=D, E, and H		S	S
RS-232, IRIG-J	S	S	S	S	S	S	S
RS-422/485 (Transmit)		S		A	A	S	S
Fault Relay(s)		S	A	A	A	S	S
Network Time Protocol (NTP) / Precision Time Protocol (PTP), IEEE 1588 Server		A	A		A
Power
Universal Power Supply	S	S	S		S	S
Low DC Power Supply		A	A		A	A
Surge Withstand Capability		A	A		A	A
Wall-mount Power Supply				S
*Physical*
Rack Mount	S	S	S	A	S	S
Table Top				S
LCD or VFD Display and/or Keypad	S	S(B/C)	S	S(B)	S(B/C)	S
Large LED Display		S(C)		S(C)	S(C)		S(C)
Special Configs and Options
Power System Time, Frequency and Phase Monitor		A	A		A
IRIG-B Distribution Bus			A
Lower Drift OCXO			A
COMTRADE Generator		A	A

Warranty Information:

The Warranty Period for Arbiter products is one year from date of delivery with the following exceptions:

Models 1084A/B/C, 1088A/B, 1092A/B/C, 1093A/B/C, 1094B, and 1095A/C are limited lifetime.

Model 1083A/B is five years from the date of delivery.
